Product Name:
Diesel Oil Filter THY-210A For Engineering Machinery
Product Attribute:
Application:
Car and Truck
Product Description:
Diesel Oil Filter THY-210A For Engineering Machinery
OEM No/Model: THY-210A
Diesel oil filter Model:THY-210A :
1. Filtering more than 90% harmful impurities in diesel fuel.
2. Drawing off 95% water
Product introduction:
TTHY-210A diesel oil filter which was mainly applied to various vehicles and low power diesel engine powered equipment below 350HP. This THY-210A oil pre-filter is used for filtering more than 90% harmful impurities for diesel engine; guarantee providing more cleaner diesel fuel for your diesel engine, attain the aim of protecting diesel engine and its "Three Filters" and saving oil. This product is different from the existed diesel filter in our market, which can not be installed directly on the diesel engine body. THY-210A oil pre-filters should be installed on the oil supply tube between the oil tank and diesel filter. In China, the product has been applied to multiple companies running oil field large equipment, truck, fishery harbors diesel engine, ect, and gained surprising achievements and praise from clients.
As is shown on the above image, we can see the product is made of aluminum alloy with two barrels in parallel mode, small-size design, compact structure, light weight and easy installation. The unique design enables the Janenope diesel fuel pre-filter to have enough capacity to contain the contaminant in addition to the sufficiently prolonged time period for filter core replacement, with several times of purification effect higher than common diesel fuel pre-filters. The multi-level integrated filtration technology adopted ensures the elimination of more than 90% of harmful impurities (including tars, pitches and mechanical impurities) in diesel fuel.
Main function:
1. Filtering more than 90% harmful impurities in diesel fuel.
2. Drawing off more than 95% water in diesel fuel.
3. Reducing vehicle emissions up to 20% to 60%,
4. Diesel fuel consumption reduced by 5% to 10%.
Main advantages:
-
Integrated multi-level filter technology
-
High filter fineness and working efficiency
-
Long replacement cycle for filter core
-
Low original resistance
Main effectiveness:
-
Decreasing fuel consumption
-
Reducing engine failure and strengthening dynamic accordingly.
-
Prolonging engine service life.
-
Reducing maintenance cost for diesel engine and its diesel filter.
Technical specifications:
Specification:
The size of vat: 252×126×361mm
The size of oil tube: M18×1.5
Rated flux: 0~10L/min
Net weight: 3.0kg
Filter core quantity: 2
Filter core model: C1020A
Applications:
Small Volume THY-210A oil pre-filters can be applied to various vehicles and engineering machinery powered by diesel engine below 350HP.
Installation diagram:
